26 Style Air Spring
Product Code: DR.07.016693
Specifications
| Part Number | DR.07.016693 |
| Air Spring Style | Style 26 |
| Cross Reference Number | W21-D60-6693 |
| Assembly Weight | 2.4 kg |
| Force to collapse to min height (@ 0 BAR) | 102 N |
| Minimum Height | 77 mm |
| Maximum Stroke | 152 mm |
| Maximum Usable Height | 225 mm |
| Thread - Mounting Fittings | Metric |
| Thread - Air Feed | Imperial |
| Loading Capacity @ 3 Bar | 3.74 kN |
| Loading Capacity @ 5 Bar | 6.52 kN |
| Loading Capacity @ 7 Bar | 9.41 kN |
| Natural Frequency Range @ 7 BAR | 1.81 Hz |
| Maximum Diameter @ 7 BAR | 218 mm |
| Operating Temperature | -37°C to 57°C |
