Drive-Rite Height Sensor - Extended Arm
Product Code:DR.35.017403
Specifications
| Part Number | DR.35.017403 |
| Height Sensor Type | Universal |
| Cross Reference Number | DRV.7403.1 |
| Mounting Holes | 2x M5 holes |
| Sensor Range | ±34° |
| Arm Length Max | 245 mm (130 mm + 115mm) |
| Fitting on Link arm | M8 x 1.5 Thread |
| Protection Rating |
IP66* *dependent on connector |
| Operating Temperature | -40°C -> 125°C |
Special Notes
- The Drive-Rite Height Sensor is supplied with a bult in rotating arm.
- The DR.35.017403 height sensor has a pre-assembled linkage arm of 130mm and an additional link arm of 115mm.
- An M8 x 1.5 threaded fitting is supplied at the end of the linkage arm.
Click thumbnail to view detailed image.
IntelliRide is a fully automatic, Electronically Controlled Air Suspension (ECAS) System. When fitted the system provides comfort while maintaining a programmed ride height irrespective of the load. Multiple vehicle heights are available at the push of a button.
The Height Sensor is a precision tool used to measure the change in height of the chassis to the axle.
