2 Corner ECU - Programmed for no Reservoir
Product Code:DR.32.012100
Specifications
| Part Number | DR.32.012100 |
| ECU Type | 2 Corner |
| Cross Reference Number | - |
| Mounting Holes | 4x M5 holes |
| Maximum Width | 165 mm |
| Maximum Height | 64 mm |
| Maximum Length | 130 mm |
| Protection Rating | IP67 |
| Operating Temperature | -40°C -> 85°C |
Special Notes
This ECU is pre-programmed to accommodate an AMK DR.12.011201 compressor and a DR.33.011201 Light duty valve block.
If a different compressor or valve block is installed contact Drive-Rite before use.
.jpg "Image for 2 Corner Light Duty IntelliRide Control Kit")
Click thumbnail to view detailed image.
IntelliRide is a fully automatic, Electronically Controlled Air Suspension (ECAS) System. When fitted the system provides comfort while maintaining a programmed ride height irrespective of the load. Multiple vehicle heights are available at the push of a button.
The Electronic Control Unit (ECU) is the centre of the ECAS systems. The ECU can be programmed to precisely control the InteliRide kit and give state of the art precision.
