4 Corner SD IntelliRide Control Kit - With Horizon Leveling

Click thumbnail to view detailed image.



IntelliRide ECAS Control

• Generic Control Kits - suits all vehicle types and applications
• Variable ride height - for access, off-road and high-speed driving
• Horizon Levelling Feature Included
• Load-levelling
• Near-constant ride frequency - load independent
• Variable spring rate with optional driver adjustment
• Optimized geometry (Drive-line angles)
• Improved Ride Quality
• Improved head lamp aim
• Easy Installation
• Calibrate through Handheld
• Windows based, user friendly calibration and diagnostic tools available on request

IntelliRide is a fully automatic, Electronically Controlled Air Suspension (ECAS) System. When fitted the system provides comfort while maintaining a programmed ride height irrespective of the load. Multiple vehicle heights are available at the push of a button. The IntelliRide system has automatic
load levelling at each height.

The IntelliRide system continuously monitors inputs and component performance as a means of increasing safety and durability. The system recognizes and responds accordingly to potholes, cross-articulation and extended turns. This intelligence prevents unnecessary activity and air consumption. The system even recognizes unachievable heights, assisting in the prevention of possible damage above or below the vehicle.
