Air Compressor - Ultimate Duty

Product Code:DR.12.019286

Specifications

Compressor Type Firestone
Part # DR.12.019286
Integrated Dryer No
Integrated Quick Release No



Electrical Data

Operating Voltage Range 9 - 16 V DC
Max. AMP Draw 19 Amps
Duty Cycle 100%
Temperature Range -40 degC to 70 degC

Pneumatic Data

Pressure Control 10.3 Bar (150 psi)
Volume Fill Time (RT) 0-10 Bar (0-145psi) in 285 sec for 7.5 litres (2.5 gallon)

Other Data

Mounting Position Multi-axis
Weight 3.88 kg (8.55 lbs)
Flow Data See Spec Image
Tube Connection 1/4" tube
Standard Filter Kit DR.12.019129



Special Notes

Use with up to 18.9 litres (5 gallon) Reservoir



Click thumbnail to view detailed image.

Ultimate Duty Compressor

The Ultimate Duty Firestone compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.

The system offers a dependable, lasting service for moderate use applications.
