Air Compressor - Medium Duty
Product Code:DR.12.019284
Specifications
| Compressor Type | Firestone |
| Part # | DR.12.019284 |
| Integrated Dryer | No |
| Integrated Quick Release | No |
Electrical Data
| Operating Voltage Range | 9 - 16 V DC |
| Max. AMP Draw | 14 Amps |
| Duty Cycle | 15% |
| Temperature Range | -40 degC to 70 degC |
Pneumatic Data
| Pressure Control | 9 Bar (130 psi) |
| Volume Fill Time (RT) | 0-120psi (8.27 bar) in 120 sec for 1 gallon |
Other Data
| Mounting Position | Multi-axis |
| Weight | 1.61 kg (3.55 lbs) |
| Flow Data | See Spec Image |
| Tube Connection | 1/4" tube |
| Standard Filter Kit |
DR.12.019129 |
Special Notes
Use with up to 3.75 litres (1 gallon) Reservoir
Click thumbnail to view detailed image.
Medium Duty Compressor
The Medium Duty Firestone compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.
The system offers a dependable, lasting service for moderate use applications.
