Air Compressor - Medium Duty
Product Code:DR.12.019271
Specifications
| Compressor Type | Drive-Rite |
| Part # | DR.12.019271 |
| Integrated Dryer | No |
| Integrated Quick Release | No |
Electrical Data
| Operating Voltage Range | 9 - 16 V DC |
| Max. AMP Draw | 14 Amps |
| Duty Cycle | 15% |
| Temperature Range | -40 degC to 70 degC |
Pneumatic Data
| Pressure Control | 9 Bar (130 psi) |
| Volume Fill Time (RT) | 0-120psi (8.27 bar) in 120 sec for 1 gallon |
Other Data
| Mounting Position | Multi-axis |
| Weight | 1.56 kg (3.45 lbs) |
| Flow Data | See Spec Image |
| Tube Connection | 1/4" tube |
Special Notes
- Use with up to 3.75 litres (1 gallon) Reservoir
- Removable Mounting Bracket
Click thumbnail to view detailed image.
Medium Duty Compressor
The Medium Duty Firestone compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.
The system offers a dependable, lasting service for moderate use applications.The DR.12.019271 compressor is designed to be as compact as possible.
- The bracket for this Compressor is removable for ease of use.
- It has an air intake built into the head of the compressor compact.
