Air Compressor - Ultimate Duty
Product Code:DR.12.019164
Specifications
| Compressor Type | Firestone |
| Part # | DR.12.019164 |
| Integrated Dryer | Yes |
| Integrated Quick Release | No |
Electrical Data
| Operating Voltage Range | 9 - 16 V DC |
| Max. AMP Draw | 28 Amps |
| Duty Cycle | 100% |
| Temperature Range | -40 degC to 70 degC |
Pneumatic Data
| Pressure Control | 6.9 bar (100 psi) |
Other Data
| Mounting Position | Multi-axis |
| Weight | 11.3 kg (25lbs) |
| Flow Data | See Spec Image |
| Tube Connection | 1/4" tube |
Click thumbnail to view detailed image.
Ultimate Duty Compressor
The Ultimate Duty Firestone compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.
The system offers a dependable, lasting service for moderate use applications.
