160 Style Air Spring
Product Code:DR.07.016869
Specifications
| Part Number | DR.07.016869 |
| Air Spring Style | Style 160 |
| Cross Reference Number | W21-760-6869 |
| Assembly Weight | 1.36 kg |
| Force to collapse to min height (@ 0 BAR) | 140 lbs |
| Minimum Height | 53.3 mm |
| Maximum Stroke | 112 mm |
| Maximum Usable Height | 165.3 mm |
| Thread - Mounting Fittings | Imperial |
| Thread - Air Feed | Imperial |
| Loading Capacity @ 2.75 Bar | 2.89 kN |
| Loading Capacity @ 4.1 Bar | 4.49 kN |
| Loading Capacity @ 5.5 Bar | 6.18 kN |
| Loading Capactiy @ 6.9 Bar | 7.82 kN |
| Natural Frequency Range @ 6.9 BAR | 2.02 Hz |
| Maximum Diameter @ 7 BAR | 183 mm |
| Operating Temperature | -37°C to 57°C |
