26 Style Air Spring

Product Code:DR.07.016693

Specifications

Part Number DR.07.016693
Air Spring Style Style 26
Cross Reference Number W21-D60-6693
Assembly Weight 2.4 kg
Force to collapse to min height (@ 0 BAR) 102 N
Minimum Height 77 mm
Maximum Stroke 152 mm
Maximum Usable Height 225 mm
Thread - Mounting Fittings Metric
Thread - Air Feed Imperial
Loading Capacity @ 3 Bar 3.74 kN
Loading Capacity @ 5 Bar 6.52 kN
Loading Capacity @ 7 Bar 9.41 kN
Natural Frequency Range @ 7 BAR 1.81 Hz
Maximum Diameter @ 7 BAR 218 mm
Operating Temperature -37°C to 57°C
